Research Group Control Systems and Process Automation

Modeling, control and diagnosis of diesel engines

Due to the increasing customer requirements and more stringent emission regulations the combustion engine is increasing in its complexity. Besides the engine performance the emissions and the reduction of fuel consumption during stationary and dynamic driving possesses significant relevance.
The Institute of Automatic Control develops new structures for the open and closed loop control of combustion engines. These can be tested on several simulation systems, e.g. Hardware-in-the-Loop Simulator at the dynamical engine test bench. Besides the control, the model-based fault diagnosis (On-Board-Diagnosis) has also become a main issue.

Control of vehicle dynamics, driver assistance systems

The increasing usage of mechatronic components for automotive steering systems, brakes and suspensions together with the electrification allows new ways for automatic driving control systems. Therefore our research projects deal with the modeling, state-estimation and identification of driving vehicle dynamics and applications for controlling vehicles for driver assistance systems and automatic driving.

Identification, control of nonlinear systems

• Identification of dynamic and static processes
• Further development of LOLIMOT
• Adjustment and design of identification methods
• Development of control structures based on nonlinear models
• Internal Model Control
• Applications for combustion engines and vehicles

Fault tolerant electric power steering

For an electric power steering (EPS) an electric actuator system in duplex, redundant arrangement is developed and tested on a power steering test bench.

Engine test bench

• High dynamic engine test bench 160kW
• Computer-guided operation of the engine test bench
• Hardware-in-the-Loop-Simulator for automotive control units
• CR Diesel engines
• FSI gasoline engines

Hardware-in-the-Loop test bench for rapid control prototyping system

• Real-time engine simulation with semi-physical real-time models of a CR diesel engine with VTG and high and low pressure exhaust gas recirculation
• • Mean value air path models (air ducts, actuators, etc.)
  • Crank angle resolved combustion chamber models (combustion, emissions)
  • Models for sensors and interfaces to the engine test bench for coupling with RCP system
• Coupling of the HiL engine simulation with the simulated RCP system from the engine test bench
• Driver and powertrain simulation to simulate driving maneuvers and test cycles (NEDC, WLTC, RDE)
• RCP system comprises a self-developed indexing system and an environment for the development of combustion and emission models as well as for the development of control unit functions
• Easy transfer of developed software to the engine test bench
